Big Button - Part 12 - Handling Project Secrets

Sat, Aug 30, 2025

15 min read

Introduction
File Changes
Let’s Test It Out!
Documentation

Introduction

💻 HACKER It is common that software needs to have some sensitive secret information that is not to be shared by anyone but the developer or development team. In some cases, not even developers, users, or devices are to be trusted with sensitive information (i.e. zero trust).

cool relevant image — **Figure:** *Suspicious crab holding the secrets to life*

Secrets can be passwords, API keys/tokens, encryption keys, or personal information. Eventually, in our case for this project, we will store and use WiFi network credentials and API Keys.

Obviously, secrets are different from configurations in that we aim to keep secrets exposure as limited as possible with a variety of techniques. As opposed to secrets, configurations are more openly visible to be changed.

Embedded systems like our Raspberry Pi Pico face unique challenges: they lack traditional filesystems or OS security features, and have limited memory for complex encryption. Additionally, physical device access often enables direct memory extraction through debug interfaces, making secret protection particularly challenging.

In the following sections, we will outline and implement a simple method to store our program secrets. This technique is very similar to our previous configuration management, except that we are keeping secrets separate, obfuscated, and out of our GitHub.com repository.

For more serious secret storage, please review the very last section of this tutorial part: Serious Secret Storage Alternatives

File Changes

For a quick indicator of what files we will add or change in this part, expand the following file tree.

16 collapsed lines
.
├── build.rs              # <--- Changes
├── .cargo
│   └── config.toml
├── Cargo.lock
├── Cargo.toml            # <--- Changes
├── configs.json
├── .git
├── .gitignore            # <--- Changes
├── memory.x
├── README.md             # <--- Changes
├── .rustfmt.toml
├── rust-toolchain.toml
├── secrets.json          # <--- Added
└── src
    ├── main.rs           # <--- Changes
    └── utility.rs        # <--- Added

`.gitignore`

Let’s begin with one of the most important parts in all of this: Ensuring that we do not commit any secrets into git history and GitHub.com.

Accidentally committing sensitive files to git history happens ALL THE TIME. So much so that it has become the source for a new activity called dorking, where individuals leverage public search engines such as GitHub search to discover hidden secrets within public code projects.

Maybe we can prevent ourselves becoming targets of dorking and just go ahead and modify our .gitignore file.

All we are going to add is the following .gitignore pattern, recursively ignoring any file containing the word secret in it.

32
# ....
33

34
# Any secrets files
35
**/*secret*

`secrets.json`

As before with the configuration file, we will add a secrets.json file that will hold all our precious sensitive secrets that will be used within our embedded Rust program. Remember, this file should only live within this project locally on your computer.

We are simply adding a initial temporary dummy secret so we can develop our secrets loading code.

1
{
2
  "super_secret_info": "Area51HasNoAliens"
3
}

`build.rs`

Here again, as with the configuration file, we are adding logic to read and parse the secrets.json file. This in turn will result in a secrets.rs Rust file that is available to the Rust program at runtime.

The good news is that we already have the same code to read and parse the configs.json. Hence, we do not need any additional dependencies to import and we are able to copy the same logic we have already written.

Let’s start off by defining the function that reads and parses the secrets.json file. We will copy logic from our already existing configuration loading code, while renaming variables and definitions appropriately.

93
// ....
94

95
/// Loads secret values from secrets.json and generates a secret.rs file
96
/// with Rust obfuscated constants for use in the embedded application
97
///
98
/// # Arguments
99
/// * `out_dir` - The target build directory path
100
/// * `secret_keys` - Array of configuration keys to extract from secrets.json
101
fn load_secrets(out_dir: &str, secret_keys: [&str; 1]) -> io::Result<()> {
102
    println!("[BUILD TASK] LOADING OBFUSCATED SECRETS");
103
    println!("Secrets output directory: {out_dir:?}");
104

105
    println!("Creating new blank 'secrets.rs' file within the output directory ...");
106
    let dest_path = Path::new(&out_dir).join("secrets.rs");
107
    let mut output_file = fs::File::create(dest_path)?;
108

109
    let project_root_dir = env::var("CARGO_MANIFEST_DIR").unwrap();
110
    let secrets_path = Path::new(&project_root_dir).join("secrets.json");
111

112
    println!("Looking for secrets file at filepath: {secrets_path:?}");
113
    if !secrets_path.exists() {
114
        let error_message = "Failed to find 'secrets.json' in the project root directory.
115
                             Please create a 'secrets.json' file with your secret values.";
116
        return Err(io::Error::new(io::ErrorKind::NotFound, error_message));
117
    };
118

119
    println!("Reading and parsing 'secrets.json' ...");
120
    let contents_raw_string = fs::read_to_string(secrets_path)?;
121
    let secret_values: serde_json::Value = serde_json::from_str(&contents_raw_string)?;
122

123
    // Verify all keys exist
124
    for secret_key in secret_keys.iter() {
125
        if !secret_values.as_object().unwrap().contains_key(*secret_key) {
126
            let error_message = format!("Key '{}' not found in 'secrets.json' file", secret_key);
127
            return Err(io::Error::new(io::ErrorKind::InvalidData, error_message));
128
        }
129
    }
130

131
    Ok(())
132
}

Now, let’s add a simple way to obfuscate the secret constants that we just loaded.

Here, obfuscation means that we are ensuring that the secret value does not appear as itself within the final embedded program binary, but as some random-looking text.

We do not want someone to be able to copy our local build binary (i.e. within target/) or extract our deployed binary from the device, and search it for obvious secrets patterns with something like the following.

# Use `strings` to output any string text before searching anything with "area"
strings extracted_firmware.bin | grep -i "area"

# Output:
# Area51HasNoAliens

WARNING

Although this is perfectly fine for hobby or prototype projects, simply XOR cipher obfuscating a secret is not enough for any serious type of embedded secrets storage. A moderately capable attacker can easily extract these obfuscated secrets.

Let’s first define a XOR key for secret obfuscation. This XOR obfuscation hides text by mathematically scrambling it with a constant key, where applying the same scrambling twice reveals the original text.

93
// ....
94

6 collapsed lines
95
/// Loads secret values from secrets.json and generates a secret.rs file
96
/// with Rust obfuscated constants for use in the embedded application
97
///
98
/// # Arguments
99
/// * `out_dir` - The target build directory path
100
/// * `secret_keys` - Array of configuration keys to extract from secrets.json
101
fn load_secrets(out_dir: &str, secret_keys: [&str; 1]) -> io::Result<()> {
28 collapsed lines
102
    println!("[BUILD TASK] LOADING OBFUSCATED SECRETS");
103
    println!("Secrets output directory: {out_dir:?}");
104

105
    println!("Creating new blank 'secrets.rs' file within the output directory ...");
106
    let dest_path = Path::new(&out_dir).join("secrets.rs");
107
    let mut output_file = fs::File::create(dest_path)?;
108

109
    let project_root_dir = env::var("CARGO_MANIFEST_DIR").unwrap();
110
    let secrets_path = Path::new(&project_root_dir).join("secrets.json");
111

112
    println!("Looking for secrets file at filepath: {secrets_path:?}");
113
    if !secrets_path.exists() {
114
        let error_message = "Failed to find 'secrets.json' in the project root directory.
115
                             Please create a 'secrets.json' file with your secret values.";
116
        return Err(io::Error::new(io::ErrorKind::NotFound, error_message));
117
    };
118

119
    println!("Reading and parsing 'secrets.json' ...");
120
    let contents_raw_string = fs::read_to_string(secrets_path)?;
121
    let secret_values: serde_json::Value = serde_json::from_str(&contents_raw_string)?;
122

123
    // Verify all keys exist
124
    for secret_key in secret_keys.iter() {
125
        if !secret_values.as_object().unwrap().contains_key(*secret_key) {
126
            let error_message = format!("Key '{}' not found in 'secrets.json' file", secret_key);
127
            return Err(io::Error::new(io::ErrorKind::InvalidData, error_message));
128
        }
129
    }
130

131
    // XOR Key - Alternating bit pattern (10100101) for simple, reversible obfuscation
132
    let xor_key: u8 = 0xA5;
133
    println!("Writing XOR key and obfuscated secrets to 'secrets.rs' ...");
134
    writeln!(output_file, "pub const XOR_KEY: u8 = 0x{:02X};", xor_key)?;
135

136
    Ok(())
137
}

Next, we will add the code that iterates over each secret, obfuscates it, and writes it to the secrets.rs file. Note the code b ^ xor_key, that applies the bitwise exclusive OR (a.k.a XOR) operator (^) to each secret with a hexadecimal value of 0xA5 (binary: 10100101).

93
// ....
94

6 collapsed lines
95
/// Loads secret values from secrets.json and generates a secret.rs file
96
/// with Rust obfuscated constants for use in the embedded application
97
///
98
/// # Arguments
99
/// * `out_dir` - The target build directory path
100
/// * `secret_keys` - Array of configuration keys to extract from secrets.json
101
fn load_secrets(out_dir: &str, secret_keys: [&str; 1]) -> io::Result<()> {
28 collapsed lines
102
    println!("[BUILD TASK] LOADING OBFUSCATED SECRETS");
103
    println!("Secrets output directory: {out_dir:?}");
104

105
    println!("Creating new blank 'secrets.rs' file within the output directory ...");
106
    let dest_path = Path::new(&out_dir).join("secrets.rs");
107
    let mut output_file = fs::File::create(dest_path)?;
108

109
    let project_root_dir = env::var("CARGO_MANIFEST_DIR").unwrap();
110
    let secrets_path = Path::new(&project_root_dir).join("secrets.json");
111

112
    println!("Looking for secrets file at filepath: {secrets_path:?}");
113
    if !secrets_path.exists() {
114
        let error_message = "Failed to find 'secrets.json' in the project root directory.
115
                             Please create a 'secrets.json' file with your secret values.";
116
        return Err(io::Error::new(io::ErrorKind::NotFound, error_message));
117
    };
118

119
    println!("Reading and parsing 'secrets.json' ...");
120
    let contents_raw_string = fs::read_to_string(secrets_path)?;
121
    let secret_values: serde_json::Value = serde_json::from_str(&contents_raw_string)?;
122

123
    // Verify all keys exist
124
    for secret_key in secret_keys.iter() {
125
        if !secret_values.as_object().unwrap().contains_key(*secret_key) {
126
            let error_message = format!("Key '{}' not found in 'secrets.json' file", secret_key);
127
            return Err(io::Error::new(io::ErrorKind::InvalidData, error_message));
128
        }
129
    }
130

131
    // XOR Key - Alternating bit pattern (01011010) for simple, reversible obfuscation
132
    let xor_key: u8 = 0xA5;
133
    println!("Writing XOR key and obfuscated secrets to 'secrets.rs' ...");
134
    writeln!(output_file, "pub const XOR_KEY: u8 = 0x{:02X};", xor_key)?;
135

136
    // Write the obfuscated constants to secrets.rs
137
    for secret_key in secret_keys.iter() {
138
        print!("  - {} (obfuscated)", secret_key.to_uppercase());
139

140
        let secret_value = secret_values[secret_key].as_str().unwrap();
141

142
        // XOR encode the secret
143
        let obfuscated: Vec<u8> = secret_value.bytes().map(|b| b ^ xor_key).collect();
144

145
        // Write the obfuscated constant as a byte array
146
        writeln!(
147
            output_file,
148
            "pub const {}_OBFUSCATED: &[u8] = &{:?};",
149
            secret_key.to_uppercase(),
150
            obfuscated
151
        )?;
152

153
        println!(" ... obfuscated and stored!")
154
    }
155

156
    println!("Successfully loaded and obfuscated all secrets from 'secrets.json'!");
157

158
    Ok(())
159
}

Our last piece for this build.rs file will be to actually implement this new load_secrets() function. This again, is the same as before with configuration loading.


12 collapsed lines
1
//! This build script runs during code compilation
2
//! Runs on host computer, where `std` Rust tools are available here
3
//! Reference: https://doc.rust-lang.org/cargo/reference/build-scripts.html
4

5
use std::env;
6
use std::fs;
7
use std::io;
8
use std::io::Write;
9
use std::path::Path;
10
use std::path::PathBuf;
11

12
/// Main build script entry point
13
fn main() {
9 collapsed lines
14
    // Put `memory.x` in our output directory
15
    let out_dir = &PathBuf::from(env::var_os("OUT_DIR").unwrap());
16
    fs::File::create(out_dir.join("memory.x"))
17
        .unwrap()
18
        .write_all(include_bytes!("memory.x"))
19
        .unwrap();
20

21
    // Ensure 'memory.x' is on the linker search path
22
    println!("cargo:rustc-link-search={}", out_dir.display());
23

24
    // Re-run for any changes to the following files
25
    println!("cargo:rerun-if-changed=build.rs");
26
    println!("cargo:rerun-if-changed=memory.x");
27
    println!("cargo:rerun-if-changed=configs.json");
28
    println!("cargo:rerun-if-changed=secrets.json");
29

30
    // Load configurations from local 'configs.json' file
31
    let configs_keys = ["number_of_messages"];
32
    load_configs(out_dir.to_str().unwrap(), configs_keys)
33
        .unwrap_or_else(|error| panic!("[ERROR] {error:?}"));
34

35
    // Load secrets from local 'secrets.json' file with XOR obfuscation
36
    let secrets_keys = ["super_secret_info"];
37
    load_secrets(out_dir.to_str().unwrap(), secrets_keys)
38
        .unwrap_or_else(|error| panic!("[ERROR] {error:?}"));
39
}
40

41
// ....

`Cargo.toml`

For the next part, and for many subsequent parts, we will need better support for our limited embedded #![no_std] environment without dynamic memory allocation (i.e. the heap).

We only have a fixed amount of memory available on our device, allocating space as we go will not work very well. Hence, we need an alternative that sets exactly how much memory we need at runtime.

Luckily, the heapless Rust crate provides a solution!

To utilize common and useful dynamic Rust data structures such as String and Vec, the heapless crate offers heapless::String and heapless::Vec for us to use. (More info on using heapless)

Let’s add this crate as a runtime dependency for our project.

10
# ....
11

12
########################################################################################
13
# Rust program dependencies
14
# Reference: https://doc.rust-lang.org/cargo/guide/dependencies.html
15
[dependencies]
16
cortex-m = "0.7"    # Core support for ARM Cortex-M microcontrollers (M33 for RP2350)
17
cortex-m-rt = "0.7" # Startup code and minimal runtime for Cortex-M
18
defmt = "1.0"       # Deferred formatting for embedded logging
19
defmt-rtt = "1.0"   # RTT (Real-Time Transfer) transport for defmt
20
heapless = "0.9"    # Fixed-size collections for no_std environments
21
panic-halt = "1.0"  # Basic panic handler that halts on panic
22

23
# ....

`src/utility.rs`

Once our program starts running within the Raspberry Pi Pico device, we need a way to load the secrets.

We will add a helper function that is able to read and de-obfuscate our loaded secrets using the originally stored XOR_KEY. Specifically, this function will simply apply another exclusive OR to our stored secret text as bytes.

1
//! Utility functions for the embedded application
2
//! This module contains helper functions that can be used throughout the project
3

4
use heapless::String;
5

6
use crate::XOR_KEY;
7

8
/// Deobfuscates a byte array that was XOR encoded with XOR_KEY
9
///
10
/// This function takes the obfuscated bytes and XORs each one with
11
/// the XOR_KEY to recover the original secret string.
12
///
13
/// # Arguments
14
/// * `obfuscated` - A byte slice containing XOR-obfuscated data
15
///
16
/// # Returns
17
/// A heapless String containing the deobfuscated text (max 256 chars)
18
pub fn deobfuscate(obfuscated: &[u8]) -> String<256> {
19
    let mut result = String::new();
20

21
    for &byte in obfuscated {
22
        // XOR the byte with our key to get original string constant
23
        let original_char = (byte ^ XOR_KEY) as char;
24
        let _ = result.push(original_char);
25
    }
26
    result
27
}

Because we are running this with limited #![no_std] environment, the function here returns a heapless String of fixed max size of 256 characters. In turn, any value coming out of this function will typically need a .as_str() to make it a string slice that we can easily use.

`src/main.rs`

Now we are getting to the final part of tying this whole secrets thing together!

Here we are loading all obfuscated secrets from the generated secrets.rs file. After that, we are simply printing the secret out to the console.

But definitely do not ever log secrets to the console. This is only done here for simple demonstration purposes and will be changed in the subsequent parts.


8 collapsed lines
1
#![no_std]
2
#![no_main]
3
#![allow(unused_variables)] // only used for development
4
#![allow(unused_imports)] // only used for development
5

6
use defmt::*;
7
use defmt_rtt as _;
8
use panic_probe as _;
9

10
use embassy_executor::Spawner;
11
use embassy_rp::config::Config;
12
use embassy_rp::gpio;
13
use embassy_time::Timer;
14

15
mod utility;
16

4 collapsed lines
17
// Loading configurations
18
// Note: This comes from the 'configs.rs' file created in 'build.rs' from 'configs.json'
19
// Note: All loaded configurations will be UPPERCASE string slice (&str) constants
20
include!(concat!(env!("OUT_DIR"), "/configs.rs"));
21

22
// Loading obfuscated secrets (XOR_KEY and _OBFUSCATED constants)
23
// Note: Similar considerations as configurations
24
// Note: Load via utility.deobfuscate()
25
include!(concat!(env!("OUT_DIR"), "/secrets.rs"));
26

27
#[embassy_executor::main]
28
async fn main(spawner: Spawner) {
13 collapsed lines
29
    // Initialize system with proper clock configuration
30
    let config = Config::default();
31
    let _peripherals = embassy_rp::init(config);
32

33
    // Parse and define a configuration value
34
    let number_of_messages = NUMBER_OF_MESSAGES.parse::<u8>().unwrap();
35

36
    info!("Number of Messages: {}", number_of_messages);
37

38
    for index in 1..=number_of_messages {
39
        info!("Hello there - {}", index);
40
        Timer::after_secs(1).await;
41
    }
42

43
    // Deobfuscate secret (The utility module accesses XOR_KEY)
44
    let super_secret_info = utility::deobfuscate(SUPER_SECRET_INFO_OBFUSCATED);
45

46
    // WARNING: Never log secrets! This is for demonstration only
47
    info!("Super Secret Info: {}", super_secret_info.as_str());
48

49
    // Start an infinite loop
50
    loop {
51
        Timer::after_secs(5).await;
52
    }
53
}

Let’s Test It Out!

Ensure our Raspberry Pi Pico 2 W and its debug probe are plugged in, connected correctly, and recognized by your computer. Then run the following command.

cargo run --release

The resulting terminal output should hopefully look like this:

   Compiling big-button v0.1.0 (/home/you/projects/big-button)
    Finished `release` profile [optimized + debuginfo] target(s) in 0.70s
     Running `probe-rs run --chip=RP235x --log-format '[{t}] {[{L}]%dimmed%bold} {{f:dimmed}:{l:dimmed}%30}: {s}' target/thumbv8m
.main-none-eabihf/release/big-button`
      Erasing ✔ 100% [####################]  12.00 KiB @  51.82 KiB/s (took 0s)
     Finished in 0.65s
[0.000359] [INFO ] main.rs:36                    : Number of Messages: 5
[0.000390] [INFO ] main.rs:39                    : Hello there - 1
[1.000424] [INFO ] main.rs:39                    : Hello there - 2
[2.000439] [INFO ] main.rs:39                    : Hello there - 3
[3.000454] [INFO ] main.rs:39                    : Hello there - 4
[4.000469] [INFO ] main.rs:39                    : Hello there - 5
[5.000504] [INFO ] main.rs:45                    : Super Secret Info: Area51HasNoAliens

Nice! Once everything is working correctly, don’t forget to git commit your changes and push them to GitHub.com.

Documentation

And as always, let’s add some documentation. We will add information to the README.md file that describes how specific secrets are used in this project.

# big-button

18 collapsed lines
Just some interesting embedded Rust tutorial series I found floating around
the internet that I wanted to try.

Run me with `cargo run --release`

## Configurations

This project contains a `configs.json` file that contains various
configuration values for this program. The program will load these
values during the build process.

Currently the following configurations are supported:

'''json
{
  "number_of_messages": "5"
}
'''

## Secrets

Create and fill in a `secrets.json` file that contains sensitive
secret constants used by this project to run correctly.

Currently the following secrets are needed:

'''json
{
  "super_secret_info": "Area51HasNoAliens"
}
'''

Serious Secret Storage Alternatives

NOTE

The goal for this section is not to get into specifics. However, it is to just make you aware of more serious alternatives. Because I am presenting a simplified secret management technique, I feel obligated to mention serious alternatives. None of the following security techniques will relate to our project.

For more serious projects such as military, financial, medical, or commercial products, you might (among other things) consider the following techniques to protect software secrets. Note that each one of these has its appropriate usage, positives, and negatives. Also note that you may even use these in combination.

Encryption

Encryption transforms your secrets into an unreadable format using mathematical algorithms, requiring a specific key to decrypt and access the original data. For embedded systems, you’ll typically encounter two approaches:

Symmetric Encryption (AES or ChaCha20)
Asymmetric Encryption (RSA or Elliptic Curve)

The main challenge with encryption is typically the encryption key management. This is where special and secure local devices could come in handy.

One-Time Programmable (OTP) Memory

OTP memory provides hardware-based secret device storage that can only be written once. Once programmed, the data becomes permanent and cannot be modified, making it ideal for storing device-unique secrets or root keys. This storage is tamper-resistant and can be read-protected from external access.

Here, the Raspberry Pi Pico 2 W (RP2350) has OTP memory, perfect for securely storing decryption keys for encrypted secrets.

ARM TrustZone

TrustZone is a type of Trusted Execution Environment (TEE) which is a system-wide security architecture that creates two parallel worlds on ARM processors:

Secure World: The “safe room” where sensitive code runs (i.e. secret handling).
Normal (Non-secure) World: The regular area where the main code runs (i.e. reading sensors) and calls code within the secure world.

TrustZone-M provides hardware-enforced isolation through secure and non-secure states that extend across the processor, memory, and peripherals.

In other terms, it’s like having two separate computers on one chip where the “secure computer” can protect secrets while the “normal computer” handles everyday tasks, and they can communicate through carefully controlled secure gateways.

The Raspberry Pi Pico 2 W (RP2350) supports this!

Centralized Cloud-Based Services

For Internet of Things (IoT) devices with reliable network connectivity, centralized cloud-based secret management can be appropriate. Services like HashiCorp Vault or AWS Secrets Manager specialize in handling the full life cycle of sensitive data. The big consideration here is having a good connection to this centralized secrets management system.

> See this Code on GitHub ▂

Good! Now that some structural project things are in place, let’s move on and configure our device system clock.
